| Quantity: 0 Pieces |
| Size: 25A |
| Pressure: 10K |
| Body Material: Bronze |
| Type: A |
The flanges of nominal diameter 40 or less shall conform to JIS B 2240-10k and the flanges of nominal diameter 50 or more shall conform to JIS B2210-10K.
However they may conform to JIS B2240-5K or JIS B2210-5K
Materials:
(1). Body: Bronze;
(2). Disc: Bronze;
(3). Stem: Brass
4. Dimensions
Type | Size | d | D | C | N-h | t | L | L1 | H1 | H | kg |
F7399 10K | 25A | 25 | 125 | 90 | 4-19 | 14 | 130 | 85 | 265 | 130 | 8.5 |
5. Drawing
