CBT3945-2002 Marine cast steel flange stop valve

CBT3945-2002 Marine cast steel flange stop valve

Quantity: 0 Pieces
Size: DN150
Pressure: 1.0MPa
Body Material: Cast Steel
Type: A, AS
  1. Available Medium: Steam, High-lukewarm water, High-temperature oil.

  2. PN: 1.0, 1.6, 2.5MPa

  3. DN (mm): 65 to 150

  4. Materials of main Parts

(1). Body: Cast Steel;

(2). Disc: High-quality carbon steel;

(3). Corrugated pipe: Stainless steel;

(4). Stem: Stainless steel

   4. Dimensions

DN

L

H ≈

t

D

D1

D2

D

b

n

Th

D

m

kg

150

480

474

9

240

208

190

15

14

12

M14

320

42

68.1

CBT 3945-2002 Marine cast steel flange stop valve.jpgCBT3945-2002 Marine cast steel flange stop valves with Corrugated pipe1.jpg
